Benchmarking PLS1 Implementations
Frédéric Bertrand
Cedric, Cnam, Parisfrederic.bertrand@lecnam.net
2025-11-18
Source:vignettes/pls1-benchmark.Rmd
pls1-benchmark.RmdOverview
The unified pls_fit() interface now drives both the
dense and streaming implementations of single-response partial least
squares regression. This vignette revisits the benchmarking workflow
with the modern API and introduces two complementary perspectives:
-
Internal comparisons that contrast the dense
(in-memory) and streaming (big-memory) backends of
pls_fit(). -
External references recorded against popular
packages such as
plsandmixOmics. These results are stored in the package to keep the vignette lightweight while still documenting performance relative to the wider ecosystem.
The chunks tagged with eval = LOCAL are only executed
when the environment variable LOCAL is set to
TRUE, allowing CRAN checks to skip the more time-consuming
benchmarks.
Simulated data
We create a synthetic regression problem with a modest latent structure and keep both dense and big-memory versions of the predictors and response so they can be reused in the benchmarking chunks.
Here is an example with n=4000 en p=50
n <- 1500
p <- 80
ncomp <- 6
X <- bigmemory::big.matrix(nrow = n, ncol = p, type = "double")
X[,] <- matrix(rnorm(n * p), nrow = n)
y_vec <- scale(X[,] %*% rnorm(p) + rnorm(n))
y <- bigmemory::big.matrix(nrow = n, ncol = 1, type = "double")
y[,] <- y_vec
X[1:6, 1:6]
#> [,1] [,2] [,3] [,4] [,5] [,6]
#> [1,] -0.56047565 -0.8209867 -0.15030748 0.8343715 -0.6992281 0.3500025
#> [2,] -0.23017749 -0.3072572 -0.32775713 -0.6984039 0.9964515 0.8144417
#> [3,] 1.55870831 -0.9020980 -1.44816529 1.3092405 -0.6927454 -0.5166661
#> [4,] 0.07050839 0.6270687 -0.69728458 -0.9801776 -0.1034830 -2.6922644
#> [5,] 0.12928774 1.1203550 2.59849023 0.7479851 0.6038661 -1.0969546
#> [6,] 1.71506499 2.1272136 -0.03741501 1.2577966 -0.6080450 -1.2554751
y[1:6,]
#> [1] 0.66723250 0.66189719 -0.77458416 0.07452428 0.28174414 0.15756565Internal benchmarks
The following chunk compares dense vs. streaming fits for both SIMPLS
and NIPALS. The dense backend receives base R matrices, while the
streaming backend consumes the big.matrix objects
directly.
internal_bench <- bench::mark(
dense_simpls = pls_fit(as.matrix(X[]), y_vec, ncomp = ncomp,
backend = "arma", algorithm = "simpls"),
streaming_simpls = pls_fit(X, y, ncomp = ncomp, backend = "bigmem",
algorithm = "simpls", chunk_size = 512L),
dense_nipals = pls_fit(as.matrix(X[]), y_vec, ncomp = ncomp,
backend = "arma", algorithm = "nipals"),
streaming_nipals = pls_fit(X, y, ncomp = ncomp, backend = "bigmem",
algorithm = "nipals", chunk_size = 512L),
dense_kernelpls = pls_fit(as.matrix(X[]), y_vec, ncomp = ncomp,
backend = "arma", algorithm = "kernelpls"),
streaming_kernelpls = pls_fit(X, y, ncomp = ncomp, backend = "bigmem",
algorithm = "kernelpls", chunk_size = 512L),
dense_widekernelpls = pls_fit(as.matrix(X[]), y_vec, ncomp = ncomp,
backend = "arma", algorithm = "widekernelpls"),
streaming_widekernelpls = pls_fit(X, y, ncomp = ncomp, backend = "bigmem",
algorithm = "widekernelpls", chunk_size = 512L),
iterations = 20,
check = FALSE
)
internal_bench_res <-internal_bench[,2:5]
internal_bench_res <- as.matrix(internal_bench_res)
rownames(internal_bench_res) <- names(internal_bench$expression)
The results highlight the trade-off between throughput and memory usage: SIMPLS shines on dense matrices, whereas the streaming backend scales to larger-than-memory inputs thanks to block processing.
External references
To avoid heavy dependencies at build time we ship a pre-computed
benchmark dataset that contrasts bigPLSR with
implementations from the pls and mixOmics
packages. The dataset was generated with the helper script stored in
inst/scripts/external_pls_benchmarks.R.
data("external_pls_benchmarks", package = "bigPLSR")
sub_pls1 <- subset(external_pls_benchmarks,task=="pls1" & !algorithm=="widekernelpls")
sub_pls1$n <- factor(sub_pls1$n)
sub_pls1$p <- factor(sub_pls1$p)
sub_pls1$q <- factor(sub_pls1$q)
sub_pls1$ncomp <- factor(sub_pls1$ncomp)
replications(~package+algorithm+task+n+p+ncomp,data=sub_pls1)
#> $package
#> [1] 24
#>
#> $algorithm
#> [1] 32
#>
#> $task
#> [1] 96
#>
#> $n
#> [1] 48
#>
#> $p
#> [1] 48
#>
#> $ncomp
#> ncomp
#> 1 3 10 100
#> 24 24 36 12
sub_pls1_wide <- subset(external_pls_benchmarks,external_pls_benchmarks$task=="pls1" & algorithm=="widekernelpls")
sub_pls1_wide$n <- factor(sub_pls1_wide$n)
sub_pls1_wide$p <- factor(sub_pls1_wide$p)
sub_pls1_wide$q <- factor(sub_pls1_wide$q)
sub_pls1_wide$ncomp <- factor(sub_pls1_wide$ncomp)
replications(~package+algorithm+task+n+p+ncomp,data=sub_pls1_wide)
#> $package
#> [1] 8
#>
#> $algorithm
#> [1] 32
#>
#> $task
#> [1] 32
#>
#> $n
#> [1] 16
#>
#> $p
#> [1] 16
#>
#> $ncomp
#> ncomp
#> 1 3 10 100
#> 8 8 12 4
sub_pls2 <- subset(external_pls_benchmarks,external_pls_benchmarks$task=="pls2" & !algorithm=="widekernelpls")
sub_pls2$n <- factor(sub_pls2$n)
sub_pls2$p <- factor(sub_pls2$p)
sub_pls2$q <- factor(sub_pls2$q)
sub_pls2$ncomp <- factor(sub_pls2$ncomp)
replications(~package+algorithm+task+n+p+ncomp,data=sub_pls2)
#> $package
#> [1] 48
#>
#> $algorithm
#> [1] 64
#>
#> $task
#> [1] 192
#>
#> $n
#> [1] 96
#>
#> $p
#> [1] 96
#>
#> $ncomp
#> ncomp
#> 1 3 10
#> 48 48 96
sub_pls2_wide <- subset(external_pls_benchmarks,external_pls_benchmarks$task=="pls2" & algorithm=="widekernelpls")
sub_pls2_wide$n <- factor(sub_pls2_wide$n)
sub_pls2_wide$p <- factor(sub_pls2_wide$p)
sub_pls2_wide$q <- factor(sub_pls2_wide$q)
sub_pls2_wide$ncomp <- factor(sub_pls2_wide$ncomp)
replications(~package+algorithm+task+n+p+ncomp,data=sub_pls2_wide)
#> $package
#> [1] 16
#>
#> $algorithm
#> [1] 64
#>
#> $task
#> [1] 64
#>
#> $n
#> [1] 32
#>
#> $p
#> [1] 32
#>
#> $ncomp
#> ncomp
#> 1 3 10
#> 16 16 32
sub_pls1
#> task algorithm package median_time_s itr_per_sec
#> 1 pls1 simpls bigPLSR_dense 0.0060451836 165.1562621
#> 2 pls1 simpls bigPLSR_big.memory 0.0035867620 275.9417591
#> 3 pls1 simpls pls 0.0020867360 469.9431634
#> 4 pls1 simpls mixOmics 0.0044788605 223.4486896
#> 5 pls1 kernelpls bigPLSR_dense 0.0441235030 22.6636584
#> 6 pls1 kernelpls bigPLSR_big.memory 0.0005215200 1733.6289782
#> 7 pls1 kernelpls pls 0.0021023160 475.5957998
#> 8 pls1 kernelpls mixOmics 0.0044129530 224.0172938
#> 13 pls1 nipals bigPLSR_dense 0.0007704311 1208.7122974
#> 14 pls1 nipals bigPLSR_big.memory 0.0064723010 154.6317423
#> 15 pls1 nipals pls 0.0023130355 423.5614303
#> 16 pls1 nipals mixOmics 0.0045207831 221.5220634
#> 17 pls1 simpls bigPLSR_dense 0.0061238625 160.2659625
#> 18 pls1 simpls bigPLSR_big.memory 0.0034934051 280.9346862
#> 19 pls1 simpls pls 0.0026201049 378.4570550
#> 20 pls1 simpls mixOmics 0.0081250110 122.0214629
#> 21 pls1 kernelpls bigPLSR_dense 0.0459685031 21.7108564
#> 22 pls1 kernelpls bigPLSR_big.memory 0.0011338961 885.9666822
#> 23 pls1 kernelpls pls 0.0026236720 383.4893703
#> 24 pls1 kernelpls mixOmics 0.0081293570 121.1046267
#> 29 pls1 nipals bigPLSR_dense 0.0017690270 544.4038157
#> 30 pls1 nipals bigPLSR_big.memory 0.0063486451 155.6316749
#> 31 pls1 nipals pls 0.0032869700 308.6738445
#> 32 pls1 nipals mixOmics 0.0082580560 121.5590611
#> 33 pls1 simpls bigPLSR_dense 0.0062094295 160.3209005
#> 34 pls1 simpls bigPLSR_big.memory 0.0035923790 275.3568879
#> 35 pls1 simpls pls 0.0046357060 207.3664119
#> 36 pls1 simpls mixOmics 0.0209913850 47.6021094
#> 37 pls1 kernelpls bigPLSR_dense 0.0498161890 20.0737957
#> 38 pls1 kernelpls bigPLSR_big.memory 0.0032459290 301.8471240
#> 39 pls1 kernelpls pls 0.0047320150 211.2860747
#> 40 pls1 kernelpls mixOmics 0.0209948905 47.6736952
#> 45 pls1 nipals bigPLSR_dense 0.0047139545 211.8381858
#> 46 pls1 nipals bigPLSR_big.memory 0.0065105130 153.5810813
#> 47 pls1 nipals pls 0.0074865180 132.9719814
#> 48 pls1 nipals mixOmics 0.0210122335 46.8847723
#> 145 pls1 simpls bigPLSR_dense 6.5033901315 0.1547340
#> 146 pls1 simpls bigPLSR_big.memory 3.5608631200 0.2812449
#> 147 pls1 simpls pls 0.3611949530 2.9793809
#> 148 pls1 simpls mixOmics 0.4746793860 2.0961402
#> 149 pls1 kernelpls bigPLSR_dense 0.0888563070 11.0521410
#> 150 pls1 kernelpls bigPLSR_big.memory 0.0596174030 16.5969947
#> 151 pls1 kernelpls pls 0.3368680336 3.1522969
#> 152 pls1 kernelpls mixOmics 0.4710328870 2.2186854
#> 157 pls1 nipals bigPLSR_dense 0.0818347905 12.0507715
#> 158 pls1 nipals bigPLSR_big.memory 6.2263474941 0.1599221
#> 159 pls1 nipals pls 0.1974032740 5.0479061
#> 160 pls1 nipals mixOmics 0.2946449011 3.3824261
#> 161 pls1 simpls bigPLSR_dense 6.1359636295 0.1626558
#> 162 pls1 simpls bigPLSR_big.memory 3.3408962340 0.2994953
#> 163 pls1 simpls pls 0.2738218415 3.2636860
#> 164 pls1 simpls mixOmics 0.7325085420 1.4078995
#> 165 pls1 kernelpls bigPLSR_dense 0.2181904176 4.6082604
#> 166 pls1 kernelpls bigPLSR_big.memory 0.1305059521 7.7058833
#> 167 pls1 kernelpls pls 0.3852149671 2.6743926
#> 168 pls1 kernelpls mixOmics 0.7455238690 1.2945480
#> 173 pls1 nipals bigPLSR_dense 0.1886118900 5.1953353
#> 174 pls1 nipals bigPLSR_big.memory 6.2367988861 0.1602238
#> 175 pls1 nipals pls 0.3296010500 3.0281963
#> 176 pls1 nipals mixOmics 0.5922050660 1.7045469
#> 177 pls1 simpls bigPLSR_dense 6.2095294170 0.1609821
#> 178 pls1 simpls bigPLSR_big.memory 3.4807222855 0.2865378
#> 179 pls1 simpls pls 0.4312646910 2.2350247
#> 180 pls1 simpls mixOmics 1.7723871550 0.5695185
#> 181 pls1 kernelpls bigPLSR_dense 0.6455497560 1.5651878
#> 182 pls1 kernelpls bigPLSR_big.memory 0.3514678876 2.7636579
#> 183 pls1 kernelpls pls 0.5371060476 1.8759850
#> 184 pls1 kernelpls mixOmics 1.8362041675 0.5476303
#> 189 pls1 nipals bigPLSR_dense 0.5208903835 1.9089468
#> 190 pls1 nipals bigPLSR_big.memory 6.2764627576 0.1592679
#> 191 pls1 nipals pls 0.7559157085 1.3152253
#> 192 pls1 nipals mixOmics 1.6296500625 0.6067950
#> 289 pls1 simpls bigPLSR_dense 0.0062788220 158.3886973
#> 290 pls1 simpls bigPLSR_big.memory 0.0041523160 235.3499445
#> 291 pls1 simpls pls 0.0049248995 202.1917049
#> 292 pls1 simpls mixOmics 0.0229660476 42.7499866
#> 293 pls1 kernelpls bigPLSR_dense 0.0506123269 19.4606804
#> 294 pls1 kernelpls bigPLSR_big.memory 0.0033179866 299.1089816
#> 295 pls1 kernelpls pls 0.0049014065 202.4541097
#> 296 pls1 kernelpls mixOmics 0.0221207505 45.1716313
#> 301 pls1 nipals bigPLSR_dense 0.0047306620 210.7978021
#> 302 pls1 nipals bigPLSR_big.memory 0.0066085235 148.0432944
#> 303 pls1 nipals pls 0.0079110935 126.1707804
#> 304 pls1 nipals mixOmics 0.0220015431 45.5108450
#> 337 pls1 simpls bigPLSR_dense 6.1752819530 0.1613928
#> 338 pls1 simpls bigPLSR_big.memory 3.3039307570 0.3007239
#> 339 pls1 simpls pls 0.5349956956 1.9629343
#> 340 pls1 simpls mixOmics 1.6342236126 0.6042950
#> 341 pls1 kernelpls bigPLSR_dense 0.6289640670 1.5716088
#> 342 pls1 kernelpls bigPLSR_big.memory 0.3496842645 2.7791228
#> 343 pls1 kernelpls pls 0.5294607366 1.9623568
#> 344 pls1 kernelpls mixOmics 1.6767431134 0.5890119
#> 349 pls1 nipals bigPLSR_dense 0.5095970975 1.9054646
#> 350 pls1 nipals bigPLSR_big.memory 6.2690384570 0.1591941
#> 351 pls1 nipals pls 0.7049397730 1.3617341
#> 352 pls1 nipals mixOmics 1.5486491710 0.6395732
#> mem_alloc_bytes n p q ncomp
#> 1 104720 1000 100 1 1
#> 2 895872 1000 100 1 1
#> 3 7479024 1000 100 1 1
#> 4 7550384 1000 100 1 1
#> 5 42461256 1000 100 1 1
#> 6 821328 1000 100 1 1
#> 7 7462504 1000 100 1 1
#> 8 7550384 1000 100 1 1
#> 13 14928 1000 100 1 1
#> 14 830224 1000 100 1 1
#> 15 8265304 1000 100 1 1
#> 16 7550384 1000 100 1 1
#> 17 107920 1000 100 1 3
#> 18 899072 1000 100 1 3
#> 19 7764576 1000 100 1 3
#> 20 12407296 1000 100 1 3
#> 21 42480456 1000 100 1 3
#> 22 840528 1000 100 1 3
#> 23 7720248 1000 100 1 3
#> 24 12304368 1000 100 1 3
#> 29 18128 1000 100 1 3
#> 30 865424 1000 100 1 3
#> 31 10122568 1000 100 1 3
#> 32 12304368 1000 100 1 3
#> 33 119120 1000 100 1 10
#> 34 910272 1000 100 1 10
#> 35 9013040 1000 100 1 10
#> 36 28992768 1000 100 1 10
#> 37 42547656 1000 100 1 10
#> 38 907728 1000 100 1 10
#> 39 8959992 1000 100 1 10
#> 40 28992768 1000 100 1 10
#> 45 29328 1000 100 1 10
#> 46 988624 1000 100 1 10
#> 47 16876368 1000 100 1 10
#> 48 28992768 1000 100 1 10
#> 145 8226320 10000 1000 1 1
#> 146 88138272 10000 1000 1 1
#> 147 722792304 10000 1000 1 1
#> 148 651508960 10000 1000 1 1
#> 149 282544 10000 1000 1 1
#> 150 80194128 10000 1000 1 1
#> 151 722624584 10000 1000 1 1
#> 152 651508960 10000 1000 1 1
#> 157 130128 10000 1000 1 1
#> 158 80282224 10000 1000 1 1
#> 159 802652584 10000 1000 1 1
#> 160 651508960 10000 1000 1 1
#> 161 8258320 10000 1000 1 3
#> 162 88170272 10000 1000 1 3
#> 163 725626656 10000 1000 1 3
#> 164 986912144 10000 1000 1 3
#> 165 474544 10000 1000 1 3
#> 166 80386128 10000 1000 1 3
#> 167 725179128 10000 1000 1 3
#> 168 986912144 10000 1000 1 3
#> 173 162128 10000 1000 1 3
#> 174 80634224 10000 1000 1 3
#> 175 965206648 10000 1000 1 3
#> 176 986912144 10000 1000 1 3
#> 177 8370320 10000 1000 1 10
#> 178 88282272 10000 1000 1 10
#> 179 738038720 10000 1000 1 10
#> 180 2161313744 10000 1000 1 10
#> 181 1146544 10000 1000 1 10
#> 182 81058128 10000 1000 1 10
#> 183 737488872 10000 1000 1 10
#> 184 2161313744 10000 1000 1 10
#> 189 274128 10000 1000 1 10
#> 190 81866224 10000 1000 1 10
#> 191 1536642048 10000 1000 1 10
#> 192 2161313744 10000 1000 1 10
#> 289 119120 1000 100 1 10
#> 290 910272 1000 100 1 10
#> 291 9013040 1000 100 1 10
#> 292 28992768 1000 100 1 10
#> 293 42547656 1000 100 1 10
#> 294 907728 1000 100 1 10
#> 295 8959992 1000 100 1 10
#> 296 28992768 1000 100 1 10
#> 301 29328 1000 100 1 10
#> 302 988624 1000 100 1 10
#> 303 16876368 1000 100 1 10
#> 304 28992768 1000 100 1 10
#> 337 8370320 10000 1000 1 100
#> 338 88282272 10000 1000 1 100
#> 339 738038720 10000 1000 1 100
#> 340 2161313744 10000 1000 1 100
#> 341 1146544 10000 1000 1 100
#> 342 81058128 10000 1000 1 100
#> 343 737488872 10000 1000 1 100
#> 344 2161313744 10000 1000 1 100
#> 349 274128 10000 1000 1 100
#> 350 81866224 10000 1000 1 100
#> 351 1536642048 10000 1000 1 100
#> 352 2161313744 10000 1000 1 100
#> notes
#> 1 Run via pls_fit() with dense backend
#> 2 Run via pls_fit() with big.memory backend
#> 3 Requires the pls package
#> 4 Requires the mixOmics package
#> 5 Run via pls_fit() with dense backend
#> 6 Run via pls_fit() with big.memory backend
#> 7 Requires the pls package
#> 8 Requires the mixOmics package
#> 13 Run via pls_fit() with dense backend
#> 14 Run via pls_fit() with big.memory backend
#> 15 Requires the pls package
#> 16 Requires the mixOmics package
#> 17 Run via pls_fit() with dense backend
#> 18 Run via pls_fit() with big.memory backend
#> 19 Requires the pls package
#> 20 Requires the mixOmics package
#> 21 Run via pls_fit() with dense backend
#> 22 Run via pls_fit() with big.memory backend
#> 23 Requires the pls package
#> 24 Requires the mixOmics package
#> 29 Run via pls_fit() with dense backend
#> 30 Run via pls_fit() with big.memory backend
#> 31 Requires the pls package
#> 32 Requires the mixOmics package
#> 33 Run via pls_fit() with dense backend
#> 34 Run via pls_fit() with big.memory backend
#> 35 Requires the pls package
#> 36 Requires the mixOmics package
#> 37 Run via pls_fit() with dense backend
#> 38 Run via pls_fit() with big.memory backend
#> 39 Requires the pls package
#> 40 Requires the mixOmics package
#> 45 Run via pls_fit() with dense backend
#> 46 Run via pls_fit() with big.memory backend
#> 47 Requires the pls package
#> 48 Requires the mixOmics package
#> 145 Run via pls_fit() with dense backend
#> 146 Run via pls_fit() with big.memory backend
#> 147 Requires the pls package
#> 148 Requires the mixOmics package
#> 149 Run via pls_fit() with dense backend
#> 150 Run via pls_fit() with big.memory backend
#> 151 Requires the pls package
#> 152 Requires the mixOmics package
#> 157 Run via pls_fit() with dense backend
#> 158 Run via pls_fit() with big.memory backend
#> 159 Requires the pls package
#> 160 Requires the mixOmics package
#> 161 Run via pls_fit() with dense backend
#> 162 Run via pls_fit() with big.memory backend
#> 163 Requires the pls package
#> 164 Requires the mixOmics package
#> 165 Run via pls_fit() with dense backend
#> 166 Run via pls_fit() with big.memory backend
#> 167 Requires the pls package
#> 168 Requires the mixOmics package
#> 173 Run via pls_fit() with dense backend
#> 174 Run via pls_fit() with big.memory backend
#> 175 Requires the pls package
#> 176 Requires the mixOmics package
#> 177 Run via pls_fit() with dense backend
#> 178 Run via pls_fit() with big.memory backend
#> 179 Requires the pls package
#> 180 Requires the mixOmics package
#> 181 Run via pls_fit() with dense backend
#> 182 Run via pls_fit() with big.memory backend
#> 183 Requires the pls package
#> 184 Requires the mixOmics package
#> 189 Run via pls_fit() with dense backend
#> 190 Run via pls_fit() with big.memory backend
#> 191 Requires the pls package
#> 192 Requires the mixOmics package
#> 289 Run via pls_fit() with dense backend
#> 290 Run via pls_fit() with big.memory backend
#> 291 Requires the pls package
#> 292 Requires the mixOmics package
#> 293 Run via pls_fit() with dense backend
#> 294 Run via pls_fit() with big.memory backend
#> 295 Requires the pls package
#> 296 Requires the mixOmics package
#> 301 Run via pls_fit() with dense backend
#> 302 Run via pls_fit() with big.memory backend
#> 303 Requires the pls package
#> 304 Requires the mixOmics package
#> 337 Run via pls_fit() with dense backend
#> 338 Run via pls_fit() with big.memory backend
#> 339 Requires the pls package
#> 340 Requires the mixOmics package
#> 341 Run via pls_fit() with dense backend
#> 342 Run via pls_fit() with big.memory backend
#> 343 Requires the pls package
#> 344 Requires the mixOmics package
#> 349 Run via pls_fit() with dense backend
#> 350 Run via pls_fit() with big.memory backend
#> 351 Requires the pls package
#> 352 Requires the mixOmics packageThe table reports median execution times (in seconds), the number of iterations and memory use per second for a representative single-response scenario. The notes column indicates the additional packages required to reproduce those measurements.
Takeaways
Dense vs streaming backends. On small/medium data that fits in RAM, in-memory implementations (e.g., pls) are typically fastest (median ≈0.36 s for SIMPLS in our runs). However, they materialize large cross-products/Gram matrices and memory grows as O(p^2) (or O(n^2) in kernel views). In contrast, bigPLSR’s streaming big-memory backend keeps memory bounded via chunked BLAS and never forms those intermediates. In our PLS2 benchmark, streaming used ~7–8× less RAM than pls (≈89 MB vs ≈732 MB median) while remaining competitive in runtime (≈3.5 s vs 0.36 s). PLS1 shows the same pattern: streaming is often fast enough while dramatically reducing memory. As n or p grow, the streaming backend scales where dense approaches become memory-limited.
